2021 Yamaha TW200 : THE DO‑IT‑ALL DUAL SPORT.
2021 Yamaha TW200:
Adaptable and comfortable with fat tires, a low seat and a smooth ride makes it a practical do‑it‑all, dual purpose machine.
A low seat, extra-wide tires, and a proven four-stoke engine have cemented the TW200’s reputation as a unique, fun-loving dual purpose ride. Whether you’re a beginner or a veteran, a camper or a city dweller, this bike guarantees good times.
2021 Yamaha TW200 Totalmotorcycle.com Key Features
TOP FEATURES
1 . Terrain- Conquering Tires
Big fat tires deliver great traction and rider comfort over a wide range of terrain, and they make the TW200 the most distinctive-looking, dual- purpose machine around.
2 . Low Seat Height
A low seat and compact chassis help inspire confidence in anyone who rides the TW200, making it one of the most user friendly on- and
off-road bikes on the market.
3 . Electric Start
The electric start and full-street equipment make the TW200
2021 Yamaha TW200 Totalmotorcycle.com Features and Benefits
ENGINE
Torquey Powerplant
Strong-pulling 196cc air-cooled, four-stroke single delivers torquey low-and mid-range power that’s perfectly suited for off-road exploring.
—
5-Speed Transmission
Smooth-shifting five-speed transmission with manual clutch puts potent powerband to the ground for maximum on- and off-road
performance.
—Smooth, Counterbalanced Engine
Internal engine counterbalancer keeps vibrations down for greater all- day comfort.
—Digital Ignition
Maintenance-free CDI ignition system ensures precise, reliable spark for peak engine performance at all rpm.
—Electric Start
The push-button electric start makes for easy and reliable starting.
—Low Maintenance Engine
Automatic cam chain tensioner means minimal maintenance and longer engine life.
CHASSIS/SUSPENSION
Plush, Long-Travel Suspension
33mm telescopic front fork with 6.3 inches of travel soaks up the bumps for a plush ride.
—Terrain-Conquering Tires
Fat 130/80-18 front and 180/80-14 rear tires provide excellent traction
and control for the TW200’s unique dual-purpose style.
—Lightweight Swingarm
Lightweight box section swingarm and single rear shock with 5.9 inches of travel enhance handling and overall comfort both on- and off-road.
—Disc Brake
Hydraulic front disc brake ensures greater stopping power with less effort.
ADDITIONAL FEATURES
Comfortable Saddle
Long, two-tone, motocross-style seat creates a balanced riding position for optimal rider movement and comfort.
Protective Fenders
The durable and wide front fender keeps mud and dirt off the rider off- road.
—Passenger-Ready
Frame-mounted passenger foot pegs provide two-up riding capability.
—Bright Illumination
Enduro-style, 60/55-watt halogen headlight features high and low beams.
—Dual Sport Lighting
Flex-mounted turn indicators offer greater durability against breakage.
—Fork Protection
Durable fork shrouds help prevent rocks and debris from damaging fork sliders.
—Complete Instruments
A speedometer with odometer and resettable trip meter as well as indicator lights for neutral and high beams plus turn signals come standard.
—Modern Battery
Dependable, low-maintenance battery.
2021 Yamaha TW200 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $4699 USD
Canada MSRP Price: $5,399 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Engine Type 196cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke 67.0mm x 55.7mm
Compression Ratio 9.5:1
Fuel Delivery Mikuni® 28mm
Ignition CDI
Transmission Constant-mesh 5-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front Telescopic fork; 6.3-in travel
Suspension / Rear Single shock; 5.9-in travel
Brakes / Front Single disc, 220mm
Brakes / Rear Drum, 110mm
Tires / Front 130/80-18
Tires / Rear 180/80-14
L x W x H 82.3 in x 32.3 in x 44.1 in
Seat Height 31.1 in
Wheelbase 52.2 in
Rake (Caster Angle) 25.8°
Trail 3.4 in
Maximum Ground
Clearance
10.4 in
Fuel Capacity 1.8 gal
Fuel Economy** 78 mpg
Wet Weight*** 278 lb
Warranty 1 Year (Limited Factory Warranty)
Color Radical Gray
2021 Yamaha TW200 – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
| ENGINE | Air-cooled, SOHC, 2-valve, single |
| DISPLACEMENT | 196cc |
| BORE AND STROKE | 67 x 55.7mm |
| COMPRESSION RATIO | 9.5:1 |
| MAXIMUM TORQUE | 1.4kg-m (10.1ft-lb)@ 7,000 rpm |
| FUEL DELIVERY | Teikei MV28 |
| ESTIMATED FUEL CONSUMPTION± | 33kpl / 93.2mpg (Imp.) |
| IGNITION / STARTING | CDI / Electric Start |
| TRANSMISSION | Constant mesh, 5-speed |
| FINAL DRIVE | Chain |
CHASSIS
| SUSPENSION (FRONT) | 33mm fork / 160mm (6.3″) wheel travel |
| SUSPENSION (REAR) | Monocross / 150mm (5.9″) wheel travel |
| BRAKES (FRONT) | 220mm disc / twin piston caliper |
| BRAKES (REAR) | Drum |
| TIRES (FRONT) | 130/80-18 |
| TIRES (REAR) | 180/80-14 |
CRITICAL DATA
| LENGTH | 2,090mm (82.3″) |
| WIDTH | 820mm (32.3″) |
| HEIGHT | 1,120mm (44.1″) |
| WHEELBASE | 1,325mm (52.2″) |
| GROUND CLEARANCE | 265mm (10.4″) |
| SEAT HEIGHT | 790mm (31.1″) |
| FUEL CAPACITY | 7 litres (1.5 imp. gallons) |
| WET WEIGHT | 126kg (278 lb) |
| COLOUR(S) | Metallic Black |
2021 Yamaha TW200 – Totalmotorcycle.com European Specifications/Technical Details
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
